Telemecanique LX1 FK 220 Contactor Coil

Manufacturer: Telemecanique

Type: Contactor Coil

Model: LX1 FK 220

Control circuit voltage (Uc): 220 … 230 V AC@ 40 … 400 Hz

Inductance of closed circuit: 4.55 H

Average resistance: 35.5 Ohm inrush at 20 °C, 915 Ohm holding at 20 °C

Frequency: 50 … 60 Hz

Inrush power: 1100 VA@40 … 400 Hz

Heat dissipation: 18 W@40 … 400 Hz

Operating time: 100 … 170 ms opening, 40 … 75 ms closing

Coil technology: Without built-in suppressor module

Ambient air temperature for operation: -5 … 55 °C
