Telemecanique XS1N08PA349 Inductive Sensor

Manufacturer:  TELEMECANIQUE SCHNEIDER

Type:  INDUCTIVE SENSOR

Series Name: General Purpose

Model: XS1N08PA349

Sensing Range: 2.5 mm

Operating Voltage: 12 … 24 V DC

Operating Current: <= 200 mA
Current Consumption, No-Load: 0…10 mA

Maximum Voltage Drop: < 2 V
Switching Frequency: <= 2500 Hz
Discrete Output Type: PNP

Switching Output: Normally Open

Sensor Design: Cylindrical M8

Connector Type: Cable 2 m, 3-Wire

Enclosure Rating: IP67

Ambient Operating Temperature: -25 … 50 °C

Diameter, Length: 8, 33 mm

Body Type: Fixed

Housing Material: Metal

Enclosure Material: Nickel Plated Brass

Mounting: Flush-Mountable

Weight: 0.035 kg
