Telemecanique XS612B1PAL10EX Inductive Sensor

Manufacturer: TELEMECANIQUE SCHNEIDER

Type: INDUTIVE SENSOR FOR HAZARDOUS AREA

Model: XS612B1PAL10EX

Application: ATEX Dust

Sensing Range: 4 mm

Operating Voltage: 10 … 58 V DC

Operating Current: 200 mA

Switching Frequency: 2500 Hz

Electrical Design: PNP

Switching Output: Normally open

Connector Type: Cable, 10 m

Enclosure Rating: IP68, IP69k

Ambient Operating temperature: -20 … 60°C

Diameter, Housing length: 12, 53 mm

Housing Material: Nickel plated brass

Sensing Face material: PPS

Mounting: Flush mountable
