Tesa 03210922 Axial Probe
New
In stock1 unitReady to ship
Axial Probe TESA GT22-D precision axial probe with ±2 mm measuring range, vacuum retraction and IP65 protection, designed for accurate industrial measurement.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Part No. | GT22-D |
| Measuring range (mm) | ± 2 |
| Nominal Measuring Force | 0,25 N |
| Measuring bolt retraction | vacuum |
| Sealing bellows | Nitrile |
| Sealing / IP Rating | IP65 (Nitrile bellows sealing) |
| Housing Diameter | 8 mm (Clamping allowed over full length) |
| Ball Insert Contact Point | Tungsten carbide Ø 3 mm |
| Repeatability | 0.01 µm (0.00001 mm) |
| Standard compliance | DIN 32876 |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101073 |
| Weight | 0,14 |
