Timken RA008RR Eccentric Locking Collar Ball Bearings

Manufacturer: Timken
Type: Eccentric Locking Collar Ball Bearings
Model: RA 008RR

Shaft Size d: 0.5 in
Outside Diameter: 40 mm
Inner Ring Width B: 19.05 mm
Outside Ring Width: 13 mm
Radius r: 0.6 mm
Center of Bearing from End S: 6.5 mm
Number of Set Screws: 2
Angle between Set Screws: 90 ⁰
Dimension d1: 28.6 mm
Dimension B1: 28.6 mm
Dimension B2: 13.5 mm
Static Load Rating: 4700 N
Dynamic Load Rating: 10700 N
Material: Bearing Steel
Bore Type: Cylindrical bore
Seal Type: Molded Shroud
