Turck BI20R-Q14-AP6X2-H1141 Inductive Ring Sensor
New
In stock3 unitsReady to ship
Inductive Ring Sensor
Inductive ring sensor with 20 mm sensing range, PNP normally open output, and IP67 protection, designed for high-speed object detection in industrial automation systems.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
TURCK BI20R-Q14-AP6X2-H1141 Inductive Ring Sensor
The TURCK BI20RQ14AP6X2H1141 inductive ring sensor is designed for reliable non-contact detection of metallic objects passing through the sensing ring. It provides stable performance at high fly-by speeds and is suitable for industrial automation and monitoring applications.
Manufacturer: TURCK
Type: Inductive Ring Sensor
Model: BI20R-Q14-AP6X2-H1141
ID No.: 1407300
| Sensing Range | 20 mm |
| Inside Ring Diameter | 20.1 mm |
| Fly-By Speed | 1 / 28 m/s |
| Operating Voltage | 10 / 30 V DC |
| Operating Current | 200 mA |
| Output Function | PNP, Normally Open (NO), 3-Wire |
| Electrical Connection | Connector, M12 x 1 |
| Material | Plastic, PBT-GF30-V0 |
| Protection Class | IP67 |
| Ambient Temperature | -25 / 70 °C |
| Dimensions | 62.5 x 30 x 14 mm |
