UKF K 140 Angular Contact Precision Bearing With Spacer Ball
New
In stock1 unitReady to ship
ANGULAR CONTACT BEARING
High-precision UKF bearing with 140 mm bore, 210 mm outer diameter, and 16° contact angle, engineered for axial/radial load performance at up to 1200 RPM with oil lubrication.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
UKF K 140 ANGULAR CONTACT PRECISION BEARING
The UKF K 140 is a high-precision angular contact bearing with a spacer ball, designed for demanding applications that require exceptional axial and radial load capacity. Engineered for reliability, it operates efficiently under high-speed conditions using either oil or grease lubrication.
Manufacturer: UKF
Type: Angular Contact Precision Bearings with Spacer Ball
Model: K 140
| Bore Diameter d | 140 mm |
| Outer Diameter D | 210 mm |
| Width | 42 mm |
| Contact Angle | 16° |
| Dynamic Load Rating | 201000 N |
| Static Load Rating | 164000 N |
| Speed Limit (Oil Lubrication) | 1200 RPM |
| Speed Limit (Grease Lubrication) | 1000 RPM |
