Wilo Stratos 50/1-12 Circulating Pump

WILO STRATOS 50/1-12 CIRCULATING PUMP

The WILO STRATOS 50/1-12 Circulating Pump is designed for efficient and reliable circulation in heating, ventilation, and air conditioning systems. With a wide operating pressure range and robust construction, it provides optimal performance in a variety of industrial applications.

Manufacturer: WILO

Type: CIRCULATING PUMP

Model: STRATOS 50/1-12

Art No.: 2090458 /19W34

Technical Specifications

• Mains Connection: 230 V
• Rated Frequency: 50/60 Hz
• Operating Pressure: 6 to 10 bar
• Port-to-Port Length: 280 mm
• Rated Speed: 1400 to 4600 1/min
• Nominal Diameter of Flanged Port: DN 50
• Pump Housing: Grey cast iron (EN-GJL-250)
• Rated Power: 25 to 590 W
• Rated Current: 0.2 to 2.6 A
• Standard Voltage: Single-phase
