Zimmer MBPS3012FS1 Clamping Element
New
In stock1 unitReady to ship
ZIMMER MBPS3012FS1 clamping element, 2000 N holding force, 4.5 to 6.5 bar operating pressure, front installation, 107 mm clamping length, 90 x 38.5 x 107 mm dimensions.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
ZIMMER Clamping Element – Model MBPS3012FS1
The ZIMMER MBPS3012FS1 clamping element from the MBPS series is engineered for high holding force and reliability. With a holding force of 2000 N, it operates with a minimum pressure of 4.5 bar and a maximum pressure of 6.5 bar. This clamping element is designed for installation from the front and features a clamping length of 107 mm. Its compact dimensions of 90 x 38.5 x 107 mm ensure easy integration into various systems, making it ideal for precision clamping tasks in industrial applications.
🔧 Technical Specifications:
- Manufacturer: ZIMMER
- Type: Clamping Element
- Series: MBPS
- Model: MBPS3012FS1
- ID No.: JG 00191252 AG / JG191252 AG
- Holding Force: 2000 N
- Operating Pressure Min.: 4.5 bar
- Operating Pressure Max.: 6.5 bar
- Installation Direction: From the front
- Max. Length Clamping: 107 mm
- Dimensions: 90 x 38.5 x 107 mm
