Balluff BES 516-371-E4-C Inductive Sensor

Manufacturer: BALLUFF

Type: INDUCTIVE SENSOR

Order Code: BES00Z3

MRN: BES 516-371-E4-C-03

Sensing Range: 1.5 mm

Operating Voltage: 10 … 30 V DC

Switching frequency: 5000 Hz

Operating current: 200 mA DC

Electrical design: PNP

Output Function: Normally open

Connector type, length: PVC Cable, 3 m

Protection Class: II

Enclosure rating: IP68

Housing: Tubular

Ambient Operating temperature: -40 … 85°C

Diameter, Housing length: 6.5 x 30 mm

Material: Stainless steel; sensing face: PBT

Mounting: Flush mountable

Supplied Accessories: 2 lock nuts

Condition: New
