Banner MQDC1-506RA Single-Ended Cordset Cable
Новинка
В наличии3 единицыГотово к отправке
Banner Engineering MQDC1-506RA Cordset Cable Industrial single-ended cordset cable with a 5-pin female M12 connector, flying leads, IP67 protection, and a 2-meter cable length for reliable signal transmission applications.
Огромный ассортимент
Глобальная доставка
Экспертная поддержка
Гарантия качества
| Part No. | 51128 |
| Ref No | 1050S |
| Cable length | 2 M |
| connector 1 | 5 -pins |FeMale/M12 |
| connector 2 | 5- wires |
| Cable information | 105C , 800V, FT1, 22AWG |
| IP Rating | IP67 |
| Connector 1 Type | M12 |
| Connector 2 Type | Flying Leads |
| Number of Ends | Single Ended |
| Connector 1 Number of Contacts | 5 |
| Coupling Nut Material | Nickel Plated Brass |
| Cable Jacket Material | PVC |
| Connector 1 Thread/Snap | Threaded |
| Cable Jacket Color | Black |
| Number of Conductors | 5 |
| Connector 1 Key Code | A |
| Wire AWG | 22 |
| Connector 1 Gender | Female |
| Outside Cable Diameter (mm) | 5.59 |
| Connector 1 Orientation | Right Angle |
| Overmold Material and Color | PUR Black |
| Minimum Temp. (Celsius) | -40 |
| Maximum Temp. (Celsius) | 70 |
| Current Rating (A) | 4 |
| Supply Voltage | 30 V dc |
| Item Status | RELEASED |
| Application | Signal |
| Connector 1 Body Size | Standard |
| Connector 1 Overmold Material and Color | PUR Black |
| Connector 1 Coupling Nut Material | Nickel Plated Brass |
| Stock key | JO-004 |
| Condition | New |
| SKU | 1099587 |
| Weight | 0,10 |
