Celduc SG464420 Phase Angle Controller

Manufacturer: Celduc
Type: Phase angle controller
Model: SG464420

Output Voltage: 400 V AC (200 … 440 V AC)
Output Current: 40 A
Control Current: 4 … 20 mA
Control voltage: 1 … 5 V
Minimum release voltage: 4 mA
Input internal resistor: 0,25 KΩ
Insulation voltage Ui: 2500/3300 V
Rated impulse voltage Uimp: 4000 V
On state voltage drop: 1,6 Vpeak
Minimum load current: 10 mARMS
Turn off time: 50 ms
Operating temperature: -40 … +85°C
Protection degree: IP20
Dimensions: 73.5 X 82.7 X 39.5 mm
