Danfoss SG 3.075A Half-Wave Rectifier

Manufacturer: Danfoss

Type: Half-wave rectifier

Model: SG 3.075A ‎

Part No: ‎8080101 ‎



Supply voltage U1: max. 575 V AC +5%, 50/60 Hz

Output voltage: 0.45 * U1 V DC Max

Output current: 2 A DC when fitted in motor terminal box or brake terminal box 2.5 A DC when fitted in switch cabinet Ambient temperature: -40°C to 40°C

Possible conductor cross-sections: max. 1.5 mm2

Weight: 0.04 kg
