FAG 22222-E1-C3 Spherical Roller Bearing

Manufacturer: FAG

Type: Spherical Roller Bearing

Model: 22222.E1-C3

Replaces: 22222E1.C3, 22222-E1-XL-C3



Dimensions

Bore Diameter d: 110 mm

Outer diameter D: 200 mm

Width B: 53 mm

Basic load ratings, radial:

Dynamic C_r: 550000 N

Static C_0r: 600000 N

Fatigue load limit, radial: 64000 N

Limiting Speed: 4100 rpm

Reference speed: 3000 rpm

Radial internal clearance: C3,Group 3 (C3

Design: E1, without central rip

Cage material: Sheet metal cage

Operating temperature: -30 … +200 °C
