Gefran 400-RR-1-000 Microprocessor Controller
The Gefran 400RR1000 Microprocessor Controller is a compact and reliable temperature and process controller designed for precise monitoring and automation. Part of the proven Gefran 400 series, it offers versatile sensor compatibility, dual relay outputs, and a durable IP65 front panel suitable for industrial applications.
Manufacturer: Gefran
Type: Microprocessor Controller
Model: 400-RR-1-000
Part No.: 400111000 / 99390372
Version: V.2.11
| Series | 400 |
| Sensor Input | Thermocouple Type J, K, R, S, T, B, E, N; Resistance Thermometer PT100; Thermistor PTC |
| Supply Voltage | 220 … 240 V AC (Standard) / 100 … 127 V AC (Optional) |
| Power Consumption | 5.5 VA |
| Frequency | 50 … 60 Hz |
| Outputs Function | 2 Output Relay |
| Output Type | 250 V AC / 5 A |
| Number of Digits | 4 |
| Material | ABS |
| Protection Class | IP65 |
| Temperature | 0 … 55 °C |
| Dimensions | 48 x 48 x 109 mm |
