Hassay Savage 11204 – Style II Keyway Broach

Manufacturer: HASSAY SAVAGE COMPANY

Type: STANDARD METRIC KEYWAY BROACH

Broach Style: II

Broach EDP No.: 11204

Tolerance: J-9

Broach Width: 4mm

Keyway Width Tolerance: 0.1570 – 0.1580

Standard Millimeter Keys: 4mm X 4mm

Body Width X OAL(in): 1/4 X 10-3/4

Min. – Max. Length of Cut: 19/64 to 1-11/16

Pressure Required for Max. L/C: 1140 lb

Attached with: HASSAY SAVAGE 22211 – STYLE II BUSHING

Manufacturer: HASSAY SAVAGE COMPANY

Type: BUSHING

Bushing EDP No.: 22211

Bushings Size: 11mm-II

Bushings Dimension: 0.4331 In

Weight: 0.10 kg

Condition: New
