Leuze RT 96K/P-1444-800-41 Photoelectric Diffuse Reflection Sensor Energetic

Manufacturer: LEUZE ELECTRONIC
Type: Photoelectric Diffuse Reflection Sensor – Energetic
Order Code: RT 96k/P-1444-800-41
Part No.: 50081178

Operating range max.: 20 … 1200 mm
Operating range: 20 … 800 mm
Response time: 0.5 ms
Delay before start up: ≤ 200 ms
Operating Voltage: 10 … 30 V DC
Output Current max.: 100 mA
Switching frequency: 1000 Hz
Electrical design: PNP
Switching output: Light/dark switching
Light source: Infrared light
Wave length: 880 nm
Connector type: M12 Connector, 4-pin
Protection class: II
Enclosure rating: IP67
Ambient Operating temperature: -20 …60°C
Dimensions: 70 x 30 x 90 mm
Weight: 150 g
Housing: Rectangular
Housing material: Polycarbonate
