Micro Detectors AM1/CP-2H Inductive Proximity Sensor

Manufacturer: Micro Detectors
Type: Inductive Proximity Sensor
Model: AM1CP2H

Sensing Range: 4 mm
Operating distance: 0 … 3,2 mm
Output type: PNP
Output Function: NC
Switching frequency: 2kHz
Operating Voltage: 10 … 30 V DC
Load current: ≤ 200 mA
Contact: Normally close
Mounting: Non-flush mountable
Housing Material: Nickel-plated brass
No. of pins: 4
Connections: M12 Plug
Active Head Material: PBT
Ambient temperature range: -25 … 70°C
Degree of protection: IP67
Dimensions: M12 x 1 / L = 64,8 mm
