RHP FC30 Four-Bolt Round Flange Unit
Новинка
В наличии1 единицаГотово к отправке
Flange Unit RHP FC30 Four-Bolt Round Flange Unit with 30 mm shaft diameter, cast iron housing, and high load capacity, designed for stable and efficient shaft support.
Огромный ассортимент
Глобальная доставка
Экспертная поддержка
Гарантия качества
| Housing No. | FC4 |
| Shaft diameter d | 30 mm |
| Overall length L | 125 mm |
| H | 80 mm |
| J | 100 mm |
| G | 10 mm |
| A | 20,5 mm |
| B | 38,10 mm |
| ISO load ratings dynamic | 19500 N |
| ISO load ratings Static | 11300 N |
| Speed | max. 5300 rev/min |
| Mounting | Round Four-Bolt Flange |
| Material, housing | Cast iron |
| Condition | New |
| Stock Key | JO-004 |
| SKU | 1097093 |
| Weight | 1,06 |
