Schneider LC1D09B7 Contactor
Контактор Контактор Schneider Electric LC1D09 B7 обеспечивает надежное переключение для промышленных систем с номинальным тепловым током 25 A, номинальным рабочим напряжением 440 V AC и вспомогательными контактами для точного управления. Создан для надежной работы с защитой IP20.
Schneider Electric LC1D09 B7 “ Contactor
The Schneider Electric LC1D09 B7 contactor is a reliable and efficient electrical switching device designed for use in various industrial applications. With its durable construction and wide operational voltage range, this contactor ensures long-lasting performance in control systems.
Manufacturer: Schneider Electric
Type: Contactor
Model: LC1D09 B7
Series: LC1D
Order No.: 034867
Power AC-3:
| Range of Product | TeSys Deca |
| Rated Coil Voltage | 24 V AC |
| Rated Operational Voltage | 440 V AC |
| Rated Operational Current AC-3 | 9 A |
| Rated Thermal Current | 25 A |
| Frequency | 50/60 Hz |
| 230 V AC | 2.2 kW |
| 400 V AC | 4 kW |
| 500/690 V AC | 5.5 kW |
| Rated Impulse Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 690 V |
| No. of Poles | 3-Pole |
| Auxiliary Contact | 1 Normally Open (NO) + 1 Normally Closed (NC) |
| Switching Voltage Min. | 17 V |
| Switching Current Min. | 5 mA |
| Rated Breaking Capacity | 250 A |
| Protection Class | IP20 |
| Ambient Temperature | -40 to 60 °C |
| Dimensions | 77 x 45 x 86 mm |
