Sick LFP0332-A4NMBS08 TDR Level Sensor
Новинка
В наличии2 единицыГотово к отправке
666,66$
TDR Level Sensor The SICK LFP0332-A4NMBS08 is a TDR level sensor with a 332 mm rod probe, IO-Link communication, and versatile outputs for reliable fluid level measurement in industrial applications.
Огромный ассортимент
Глобальная доставка
Экспертная поддержка
Гарантия качества
| Part No. | 1071924 |
| Ref No | 1814 0039 |
| Series | LFP cubic |
| Medium | Fluids |
| Measurement | Switch, Continuous Design Standard |
| Probe type | Rod probe |
| Communication interface | IO-Link |
| Probe length | 332 mm |
| Process pressure | –1 bar ... 10 bar |
| Process temperature | –20 °C ... +100 °C |
| Accuracy of sensor element | ± 5 mm |
| Reproducibility | 2 mm |
| Resolution | 2 mm |
| Response time | 400 ms |
| Supply voltage | 12 V DC ... 30 V DC |
| Class | 2 |
| Power consumption | 100 mA at 24 V DC without output load |
| Protection class | III |
| Connection type | Round connector M12 x 1, 5-pin |
| Output signal | 1 x PNP + 1 x PNP/NPN + 4 mA ... 20 mA / 0 V ... 10 V |
| Switching output | IO-Link, 1 x PNP + 1 x PNP/NPN |
| Hysteresis | Min. 2 mm, free adjustable |
| Output current | 100 mA |
| Enclosure rating IP67 | EN 60529 |
| Process Connection | G ¾ A |
| Housing material | Plastic PBT |
| Stock key | CON003 |
| Condition | New |
| SKU | 1100997 |
| Weight | 0,46 |
