Siemens 6AV2 124-0GC01-0AX0 Touch Panel
399,99$
Панель управления Siemens 6AV2 124-0GC01-0AX0 SIMATIC HMI TP700 Comfort сенсорная панель обеспечивает высокое разрешение дисплея, интуитивное управление и надежную работу для передовых промышленных автоматизированных систем.
Siemens 6AV2124-0GC01-0AX0 Touch Panel
The Siemens 6AV21240GC010AX0 Touch Panel from the SIMATIC HMI TP700 Comfort range is a high-performance operator interface designed for advanced industrial automation systems. Featuring a wide TFT display, intuitive touch control, and robust communication interfaces, it ensures smooth monitoring and control of complex processes.
Manufacturer: Siemens
Type: Touch Panel
Model: 6AV2 124-0GC01-0AX0
Alternative Model: C-K8U96081 / AC-64-17-2B-B7-50
| Range | SIMATIC HMI TP700 Comfort |
| Display Design | TFT Wide |
| Screen Diagonal | 7 In |
| Resolution | Horizontal 800 / Vertical 480 Pixel |
| Colors No. | 16 Million |
| Pre-Installed Operating System | Windows CE |
| Control Elements | Touch Screen |
| Protocols Ethernet | TCP/IP, DHCP, SNMP, DCP, LLDP |
| WEB Characteristics | HTTP, HTTPS, HTML, XML, CSS, Active X, JavaScript, Java VM |
| Supply Voltage | 24 V DC |
| Current Consumption | 0.5 A |
| Memory Type | Flash / RAM |
| Memory Available for User Data | 12 Mbyte |
| Ethernet Interfaces | RS 422/485 Combined |
| Industrial Ethernet Interface | 1; 2 Ports (Switch) |
| USB Port | 2 x USB 2.0 |
| SD Card Slot | 2 Slot |
| Processor Type | X86 |
| Protection Class | IP20 / IP65 |
| Ambient Temperature | 0 / 50 °C |
| Dimensions | 158 x 214 x 63 mm |
