Telemecanique XCS-E7311 Safety Switch
Безопасный выключатель Безопасный выключатель Telemecanique XCSE7311 предоставляет номинальное напряжение 24/48 В AC/DC, импульсное напряжение выдержки 4 кВ и рабочий ток 6 А, идеально подходит для промышленных систем безопасности.
Telemecanique XCSE7311 Safety Switch
The **Telemecanique XCSE7311 Safety Switch** is designed for industrial safety applications, offering **24/48 V AC/DC rated voltage** and a **rated impulse withstand voltage** of **4 kV**. With **2 NC** and **1 NO contacts**, it supports **slow-break, break-before-make contact operation**. This safety switch is ideal for high-demand environments with **6 A rated operational current** at **24/48 V** and **IP67** protection, making it highly durable and reliable.
Manufacturer: Telemecanique
Type: Safety Switch
Model: XCSE7311
The **Telemecanique XCSE7311 Safety Switch** ensures safe operation with high durability, offering optimal protection in a variety of industrial safety-critical environments.
| Rated Voltage | 24/48 V AC/DC |
| Supply Frequency | 50/60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Conventional Enclosed Thermal Current (Ith) | 6 A |
| Signaling Circuit Consumption | 7 mA |
| Design | Rectangular |
| Head Type | Key Operated Turret Head |
| Contacts Type and Composition | 2 NC, 1 NO |
| Contact Operation | Slow-Break, Break-Before-Make |
| Solenoid Contacts Type and Composition | 1 NC + 1 NO (Slow-Break, Simultaneous) |
| Rated Operational Current | 6 A at 24/48 V AC15-0.55 A at 24/48 V DC13 |
| Cable Entry | 2 Entries Tapped for Pg 13.5 |
| Number of Poles | 3 |
| Body Material | Zamak |
| Head Material | Zamak |
| Standard | IEC/EN 60947-5-1 |
| Degree of Protection | IP67 |
| Dimensions | 44 x 146 x 98 mm |
