ABB MS116-4.0 Manual Motor Starter

Manufacturer: ABB
Type: Manual Motor Starter
Model: MS1164.0

Rated Operational Voltage: 690 V AC
Rated Operational Current: 2.5 … 4 A
Rated Insulation Voltage: 690 V
Power Loss: 0.7 … 1.8 W
Frequency: 50 … 60 Hz
Power AC-3: 1.5 kW
Horsepower: 0.75 … 3 HP
Rated Impulse Voltage (Uimp): 6 kV
Rated Service Short-Circuit Breaking Capacity (Ics): 50 … 2 kA
Rated Short-Circuit Breaking Capacity (Icu): 50 … 2 kA
Contact: 3-Pole, 3 Normally Open (NO)
Protection Class: IP20
Ambient Temperature: -25 … 70 °C
Dimensions: 90 x 45 x 85.6 mm
