Advanced BE25A20ACE Brushless PWM Servo Amplifier
Neu
Auf Lager1 EinheitVersandbereit
BRUSHLESS PWM SERVO AMPLIFIER
BE25A20ACE from ADVANCED Motion Controls is a high-performance brushless PWM servo amplifier with encoder velocity mode, 25 A peak current, and 30“125 VAC input range.25AAdvancedAmplifierBE25A20ACEBrushlessControllerControlsDriveEncoderHighIndustrialModeMotionPWMServoVelocityvoltage
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
ADVANCED Motion Controls BE25A20ACE Brushless PWM Servo Amplifier
The BE25A20ACE is a robust brushless PWM servo amplifier from ADVANCED Motion Controls, designed for high-performance motion control applications. It supports encoder velocity mode and delivers precise control in demanding automation environments.
Manufacturer: ADVANCED Motion Controls
Type: Brushless PWM Servo Amplifier
Model: BE25A20ACE
Part No.: 14219-0003
| Input Voltage | 30 “ 125 VAC |
| Input Frequency | 50/60 Hz |
| Fuse Voltage | 250 VAC |
| Fuse Current | 16 A |
| Drive Type | BE; Encoder Velocity Mode Available |
| Maximum Peak Current Rating | 25 A |
| Peak Voltage Rating (scaled 1 | 10): 20 V |
