Allen-Bradley 1734-SSI Point I/O Synchronous Serial Interface Absolute Encoder Module
SSI-Encoder-Schnittstellenmodul Allen-Bradley 1734-SSI ist ein Point I/O SSI-Modul, das absolute Encoder unterstützt, flexible Datenraten bis zu 2 MHz bietet und explosionsgeschützt für anspruchsvolle Umgebungen ist.
ALLEN-BRADLEY 1734-SSI POINT I/O ABSOLUTE ENCODER MODULE
The Allen-Bradley 1734-SSI is a high-performance Point I/O Synchronous Serial Interface (SSI) module, designed to connect absolute encoders within industrial automation systems. It provides flexible data rates and high reliability in harsh environments, including hazardous areas requiring explosion protection.
Manufacturer: ALLEN-BRADLEY
Type: POINT I/O Synchronous Serial Interface Absolute Encoder Module
Model: 1734-SSI
Part No.: 92433071
Ref No.: SS1PQ0TT / 04 ATEX 0330347 X
| Number of SSI Channels | 1 |
| SSI Data Rate | 125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz (software selectable) |
| SSI Word Length | 4 bytes (32 bits) |
| On-State Voltage / Current | 0 VDC / 2 mA |
| Off-State Voltage / Current | FPV-5 / 1.2 mA |
| SSI Sensor Power | 450 mA, 10 / 28.8V DC |
| Explosion Proof | EX nA IIC T4 |
| SSI Clock Drive Current | 125 mA |
