Alpha SP 100S-MF1-5-1E1-2S Planetary Gearbox
Planetengetriebe Wittenstein Alpha SP 100S-MF1-5-1E1-2S einstufiges Planetengetriebe mit Übersetzung 5, hoher Drehmomentkapazität, maximaler Eingangsdrehzahl 8500 U/min und wartungsfreier Schmierung. Empfohlen für präzise Automatisierungssysteme und servobetriebene Anwendungen.
Wittenstein Alpha SP 100S-MF1-5-1E1-2S Planetary Gearbox
The Wittenstein Alpha SP 100S-MF1-5-1E1-2S is a precision single-stage planetary gearbox engineered for high-performance motion control and industrial drive applications requiring high torque transmission and accurate positioning.
Manufacturer: Wittenstein Alpha / Artisan
Type: Planetary Gearbox
Model: SP 100S-MF1-5-1E1-2S
Serial No.: 2750528
Suitable for integration with high-precision servo motors in automated machinery and dynamic motion systems.
Please contact us via Ask for assistance with any inquiries.
| Ratio [i] | 5 |
| Max./Nominal Torque [Nm] | 48 / 5700 |
| Max. Input Speed | 8500 rpm |
| Oil Specification | Castrol Tribol 800/220 |
| Number of Stage | 1 |
| Shaft Diameter | 32 mm |
| Hollow Shaft Diameter | 18 mm |
| Flange Diameter | 120 mm |
| Output Shaft Type | Solid Shaft |
| Lubrication Type | Lubricated for Life |
