Beckhoff CU8802-0000 Transmitter BOX
Neu
Auf Lager1 EinheitVersandbereit
Transmitter Box The Beckhoff CU8802-0000 is a 24 V DC CP-Link 4 transmitter box with USB, DVI-D and RJ45 interfaces for reliable industrial display transmission.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Serial No. | 1711000101689 |
| Rev. | 1.1 |
| Used for | CP-Link-4 The Two Cable Display Link |
| Power Supply | 24 V DC |
| Interfaces | 1 USB Input With USB B Socket To Be Connected To The PC At a Maximum Distance Of 1 m / 1 DVI Input With DVI-D Socket To Be Connected To The PC At a Maximum Distance Of 1 m / 1 CP-Link 4 Output With RJ45 Socket For Up To 100 m Cat. 6 A Cable |
| Connection | Connector Cable 1 m USB 2.0 USB-A to USB-B |
| Material | Metal |
| Protection Class | IP20 |
| Operating Temperature | 0 … 55 °C |
| Dimensions | 45 x 100 x 80 mm |
| Approvals/Markings | CE, ATEX, IECEx (requires C9900-Z484), CE |
| Ex Marking | II 3 G Ex nA IIC T4 Gc / II 3 D Ex tc IIIC T135 °C DC |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1104182 |
| Weight | 0,35 |
