Fairchild 10294 Pneumatic Precision Regulator

Manufacturer: FAIRCHILD

Type: Pneumatic Precision Regulator

Part No.: 10294

Elastomer: Nitrile on Dacron

Exhaust Capacity: 5.5 SCFM [9.36m3/Hr] where downstream

Exhaust Type: Straight (standard)

Flow Capacity: 40 SCFM (68 M³/HR)

Pipe Size: 1/2 FNPT

Pressure Range: 0 to 400 psig

Product Type: Precision Pressure Regulators

Sensitivity: 1/8 in. W.C.

Supply Pressure: 500 psi

Trim: Zinc-Plated Steel Brass

Accuracy: 0.10 psi

Ambient Temperature: -40° to 93.3 °C

Body Material: Aluminum

Connection Size: 1/2 in. NPT
