Dhsg YLD-S1077-13 Ball Screw
Neu
Auf Lager1 EinheitVersandbereit
Ball Screw The DHSG YLD-S1077-13 is a precision 25 x 10 R ball screw designed for smooth, accurate, and reliable linear motion in industrial machinery and automation systems.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Code | YLD-S1077-13/420123 |
| Size | 25 x 10 R |
| Nominal Diameter | 25 |
| Lead P | 10 |
| Number of starts | 1 |
| Direction of Lead | Right-Hand Thread |
| Nut outer diameter | 54 mm |
| Flange diameter | 79 mm |
| Flange thickness | 12 mm |
| Nut length | 86.5 mm |
| Threaded length | 375 mm |
| Total screw length | 505 mm |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101080 |
| Weight | 3,05 |
