Elcon Instruments 412 Intrinsic Safety Specialist

Manufacturer: ELCON INSTRUMENTS

Type: Intrinsic Safety Specialist 2 Channel Isolating Contact/ Prox. Sensor Repeater-Spdt Outputs

Model: 412

DC Supply:

Voltage: 24 VDC (20-30V)

Current: 30 mA (36 mA max)

Power Dissipation: 0.72 W

AC Supply:

Voltage: 98 … 264 VAC

Frequency: 48 … 62 Hz

Current: 37 mA (115 VAC) … 75 mA (230 VAC)

Power Dissipation: 1 W

Ambient Temperature: 60 °C

Dimensions: 17 X 112.5 X 92.3 mm

Weight: 0.21 Kg
