Sensors & Measurement Vibrating / Tuning Fork Level Switch

Endress Hauser FTL 260-0010 Vibration Limit Switch

Name: ENDRESS HAUSER FTL 260-0010 VIBRATION LIMIT SWITCH
SKU: 1041023
Availability: LimitedAvailability

endress-hauser-FTL-260-0010-vibration-limit-switch-used

endress-hauser-FTL-260-0010-vibration-limit-switch-used-2

endress-hauser-FTL-260-0010-vibration-limit-switch-used-3

endress-hauser-FTL-260-0010-vibration-limit-switch-used-4

Gebraucht

Auf Anfrage verfügbar

Hersteller: ENDRESS+HAUSER Typ: Vibrationsgrenzschalter Modell: FTL260 Bestellcode: FTL 260-0010

Hersteller

Endress-Hauser

SKU

1041023

Kategorie

Vibrating / Tuning Fork Level Switch

Zustand

Gebraucht

Endress+Hauser Instrumentation Instrumentations Limit Switch Vibration

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Manufacturer: ENDRESS+HAUSER
Type: Vibration Limit Switch
Model: FTL260
Order Code: FTL 260-0010

The Liquiphant is a limit switch for liquid level detection in storage tanks, tanks with agitators, and piping
Switch Point: 118 mm
Sensor Length: 130 mm
Process Connection: G 1 A (parallel)
Electronics: Two-wire AC connection 12 … 253 V DC
Frequency: 50 … 60 Hz
Voltage drop across: max. 12 V
Switching time: Approx. 0.5 s when covered, approx. 1.0 s when free
Operating pressure: – 1 bar … +40 bar
Density of medium: min. 0,7 g/cm3
Material:
Process connection and vibrating fork: stainless steel 1.4571,
1.4581 (AISI 316 Ti)
Housing: stainless steel 1.4404 (AISI 316 L)
Enclosure Rating: IP65/67
