FAG 1205TV.C3 Self-Aligning Ball Bearing
Selbstausrichtendes Kugellager Das FAG 1205TV.C3 Lager verfügt über einen Bohrungsdurchmesser von 25 mm, einen Außendurchmesser von 52 mm und eine C3-Teilung, konzipiert für Ausrichtungsfehlerausgleich und einen reibungslosen Betrieb in anspruchsvollen Anwendungen.
FAG 1205TV.C3 Self-Aligning Ball Bearing
The FAG 1205TV.C3 Self-Aligning Ball Bearing is designed to accommodate misalignment and ensure smooth operation under varying conditions. With a high-performance glass-fiber reinforced polyamide cage and C3 internal clearance, this bearing provides excellent durability and load-handling capabilities.
Manufacturer: FAG
Type: SELF-ALIGNING BALL BEARING
Model: 1205TV.C3
This self-aligning ball bearing is ideal for applications requiring automatic adjustment to shaft misalignment while maintaining operational efficiency and extended service life.
| Bore Diameter (d) | 25 mm |
| Outer Diameter (D) | 52 mm |
| Width | 15 mm |
| Dynamic Load Rating | 12,300 N |
| Static Load Rating | 3,300 N |
| Fatigue Load Limit | 209 N |
| Limiting Speed | 15,500 1/min |
| Reference Speed | 13,400 1/min |
| Cage | TV, Solid cage made of glass-fiber reinforced polyamide PA66 |
| Bore Type | Cylindrical |
| Radial Internal Clearance | C3 |
