FAG 1218TV Self-Aligning Ball Bearing
Neu
Auf Lager1 EinheitVersandbereit
Selbstausrichtendes Kugellager Das FAG 1218TV Selbstausrichtende Kugellager bietet hohe Tragfähigkeit, Selbstausrichtungsfähigkeiten und einen langlebigen Polyamid PA66 Käfig, ideal für industrielle Anwendungen.
1218TV160mm90mmBallbearingboreCageCapacitydiameterdurableFaghigh-loadIndustrialMachineryPA66PolyamideSelf-Aligning
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
FAG 1218TV Self-Aligning Ball Bearing
The FAG 1218TV Self-Aligning Ball Bearing is engineered for applications requiring high-load capacity and self-alignment capabilities. With a solid glass-fiber reinforced polyamide PA66 cage, this bearing offers durability and stability, ensuring smooth operation in industrial machinery.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 1218TV
Basic Load Ratings:
Speeds:
| Bore Diameter (d) | 90 mm |
| Outer Diameter (D) | 160 mm |
| Width (B) | 30 mm |
| Dynamic (Cr) | 57,000 N |
| Static (C0r) | 23,500 N |
| Fatigue Load Rating | 1,330 N |
| Limiting Speed | 4,550 1/min |
| Reference Speed | 4,850 1/min |
| Cage | TV, solid cage made of glass-fiber reinforced polyamide PA66 |
