FAG 21315-E1-TVPB Spherical Roller Bearing

Manufacturer: Schaeffler FAG

Type: Spherical Roller Bearing

Model: 21315 E1-TVPB

Replaces: 21315-E1-XL-TVPB, 21315E1TVPB

Dimensions:

Bore Diameter d: 75 mm

Outer diameter D: 160 mm

Width: 37 mm

Dynamic load rating: 305000 N

Static load rating: 325000 N

Fatigue load limit: 39000 N

limiting speed: 5700 RPM

Reference speed: 3750 RPM

Cage material: Plastic cage

Operating temperature: -30 … +120 °C
