FAG 22318-E1-K-C3 Spherical Roller Bearing
Manufacturer: FAG
Type: Spherical Roller Bearing With Tapered Bore
Model: 22318 E1-K-C3
Replaces: 22318E1K.C3, 22318-E1-XL-K-C3
Dimensions
Bore Diameter d: 90 mm
Outer diameter D: 190 mm
Width B: 64 mm
Basic load ratings, radial:
Dynamic Cr: 610000 N
Static C0r: 630000 N
Fatigue load limit, radial: 56000 N
Limiting Speed: 3850 rpm
Reference speed: 3000 rpm
Bore type: Tapered bore, taper 1:12
Radial internal clearance: C3,Group 3 (C3
Design: E1, without central rip
Cage material: Sheet metal cage
Operating temperature: -30 … +200 °C
