FAG 23120-E1A-K-M-C3 Spherical Roller Bearing

Manufacturer: Schaeffler FAG

Type: Spherical Roller Bearing with tapered bore

Model: 23120 E1A K M C3

Replaces: 23120-E1A-XL-K-M-C3, 23120E1AK.M.C3

Dimensions:

Bore Diameter d: 100 mm

Outer diameter D: 165 mm

Width: 52 mm

Bore type: Taper 1:12

Dynamic load rating: 450000 N

Static load rating: 570000 N

Fatigue load limit: 54000 N

limiting speed: 4000 RPM

Reference speed: 2750 RPM

Cage material: Brass

Operating temperature: -30 … +200 °C
