FAG B7208c.TPA.P4 ANGULAR CONTACT BALL BEARING

Manufacturer: Schaeffler FAG

Type: Spindle Bearing

Part No:  B7208c.TPA.P4 ‎

Replaces: B7208-C-T-P4S-UL, B7208C.T.P4S.UL

Bore Diameter: 40 mm

Outer diameter: 80 mm

Width: 18 mm

Chamfer r_min: 1.1 mm

Contact Angle: 15°

Basic load ratings:

Dynamic C_r: 32.5 kN

Static C_0r: 16.1 kN

Fatigue load rating: 1.7 kN

Limiting speed – Grease : 18000 rpm

Limiting Speed – Oil : 30000 rpm

Cage: Laminated fabric cage

Tolerance: tolerance class P4S, FAG standard better than P4 to DIN 620

Weight: 0.4 kg
