FAG NN3016KM.SP Cylindrical Roller Bearing

Manufacturer: Schaeffler FAG

Type: Cylindrical roller bearing with tapered bore

Model: NN 3016 KM.SP

Dimensions:

Bore Diameter d: 80 mm

Outer diameter D: 125 mm

Width: 34 mm

Bore type: Tapered Bore, Taper 1:12

Radial internal clearance: C1

Tolerance class: SP

Cage material: Brass cage

Operating temperature: -30 … +150 °C
