FAG RNA4914 Needle Roller Bearing

Manufacturer: Schaeffler FAG
Type: Needle Roller Bearing
Model: RNA4914
Replaces: RNA4914-XL

Dimensions
Under roller diameter Fw: 80 mm
Outer diameter D: 100 mm
Width B: 30 mm
Minimum chamfer dimension rmin: 1 mm
Basic load ratings:
Dynamic C_r: 95000 N
Static C_0r: 156000 N
Fatigue load limit C_ur: 28000 N
Limiting speed: 5700 rpm
Limiting speed for grease: 3400 rpm
Reference speed: 3400 rpm
Operating temperature:  -30 … +120 °C
