PNEUMATIC VALVE
FESTO VL/O-3-3/4 pneumatic valve with 3/2-way monostable function, high 7500 l/min flow rate, and poppet seat design for reliable industrial air control.3/2-wayAirAluminiumconnectiondie-castFestoflowG3/4HighIndustrialMonostablePneumaticPoppetSeatValveVL/O-3-3/4
Neu
Auf Lager
Dieses Produkt ist auch als nagelneu erhältlich.
Neue Version anzeigen →
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
FESTO VL/O-3-3/4 PNEUMATIC VALVE
The FESTO VL/O-3-3/4 pneumatic valve is engineered for robust air control in demanding industrial environments. Featuring a poppet seat design and monostable 3/2-way function, it supports high flow rates with stable pneumatic actuation and reliable sealing.
Manufacturer: FESTO
Type: Pneumatic Valve
Model: VL/O-3-3/4
Part No.: 10049
| Fluid | Air |
| Design | Poppet seat |
| Function | 3/2-way, monostable, open/closed |
| Type of Actuation | Pneumatically |
| Operating Pressure | -0.95 to 10 bar |
| Pilot Pressure | 1 to 10 bar |
| Nominal Flow Rate | 7500 l/min |
| Pneumatic Connection | G3/4 |
| Material | Die-cast aluminium |
| Ambient Temperature | -10 to 60 °C |
