Festo 10521 Flow Control Valve
Neu
Auf Lager3 EinheitenVersandbereit
Flow Control Valve
The FESTO GRL-1/4-S9 is a one-way adjustable flow control valve for compressed air, with G¼ connection and up to 420 l/min flow at 10 bar.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
FESTO GRL-1/4-S9 Flow Control Valve
The FESTO GRL-1/4-S9 (Part No. 10521) is a precision-engineered flow control valve for use in pneumatic systems. Designed for adjustable flow in one direction, it ensures optimal regulation of compressed air under a wide range of pressures and temperatures.
Manufacturer: FESTO
Type: Flow Control Valve
Model: GRL-1/4-S9
Part No.: 10521
| Medium | Compressed air, filtered, lubricated or unlubricated |
| Design | Flow control valve, adjustable in one direction |
| Connection | G¼ |
| Nominal Size in Throttle Direction | 4.5 mm |
| Nominal Size in Free Flow Direction | 5 mm |
| Standard Nominal Flow Rate in Throttle Direction | 0 to 420 l/min |
| Standard Nominal Flow Rate in Free Flow Direction | 285 l/min |
| Pressure Range | 0.3 to 10 bar |
| Temperature Range | “10 to +60 °C |
