Compact Air Cylinder
The Festo ADVULQ-16-10-P-A-S2 is a double-acting compact air cylinder with a 16 mm piston diameter and 10 mm stroke. It offers versatile rod design options and reliable operation under 1.3 to 10 bar pressure, featuring elastic cushioning at both ends.16ActingActuatorADVULQ-16-10-P-A-S2AirAlloyAluminumCompactCushioningCylinderDoubleElasticFestommPistonPneumaticwrought
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Festo ADVULQ-16-10-P-A-S2 “ Compact Air Cylinder
The Festo ADVULQ-16-10-P-A-S2 compact air cylinder is designed for versatile and efficient actuation in confined spaces. Featuring a robust construction with both square and circular rod design options, it provides reliable performance under varying operational conditions.
Manufacturer: Festo
Type: Compact Air Cylinder
Model: ADVULQ-16-10-P-A-S2
Part No: 156111 UO08
| Operating Medium | Compressed air |
| Design of Cylinder | Piston |
| Rod Direction | Both sides |
| Design of Rod | Square and circular |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Piston Rod End | Female thread |
| Mode of Operation | Double-acting |
| Operating Pressure | 1.3 to 10 bar |
| Piston Diameter | 16 mm |
| Stroke | 10 mm |
| Pneumatic Connection | 5 mm |
| Cover Material | Wrought aluminum alloy |
| Material of Dynamic Seals | NBR |
| Piston Rod Material | High-alloy stainless steel |
| Ambient Temperature Range | -20 to 80°C |
