Festo 1908255 Round Cylinder
Round Cylinder
FESTO DSNU-12-15-P-A Round Cylinder is a compact and high-precision pneumatic actuator designed for industrial applications. With a 12 mm piston diameter, 15 mm stroke length, and double-acting operation, it ensures efficient motion control. Featuring an external thread piston-rod end and a 5 mm port size, it provides reliable performance across a wide pressure range.FESTO DSNU-12-15-P-A Round Cylinder
The FESTO DSNU-12-15-P-A Round Cylinder is a high-performance pneumatic actuator designed for precise motion control in automation and industrial applications. Its compact and lightweight construction ensures efficient force transmission while maintaining durability in demanding environments.
Manufacturer: FESTO
Type: Round Cylinder
Model: DSNU-12-15-P-A
Part No.: 1908255
| Fluid | Compressed Air |
| Piston Diameter | 12 mm |
| Stroke Length | 15 mm |
| Operating Pressure | 1.5 / 10 bar |
| Piston-Rod End | External Thread |
| Operation Mode | Double Acting |
| Port Size | 5 mm |
| Ambient Temperature | -20 / 80 °C |
