Pneumatic System Air Preparation Equipment

Festo 192322 Pressure Regulator

Name: FESTO 192322 PRESSURE REGULATOR
SKU: 1062910
Availability: LimitedAvailability

Neu

Auf Lager2 EinheitenVersandbereit

Pressure Regulator

The FESTO LR-1/2-D-I-MIDI Pressure Regulator ensures precise pressure control with a wide regulation range and high flow rate, designed for **compressed air** and **inert gas** systems in industrial environments.

SKU

1062910

Kategorie

Air Preparation Equipment

Zustand

Neu

0.5 1/2 16 3500 Air Ambient Application bar Compressed connection die-cast Festo flow G Gas Industrial Inert l/min LR-1/2-D-I-MIDI Midi Nominal Pneumatic Pressure Range Rate Regulation regulator Temperature Zinc

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

FESTO LR-...-D-I-MIDI Pressure Regulator

The FESTO LRDIMIDI Pressure Regulator ensures precise pressure control for compressed air and inert gas systems. Constructed with durable die-cast zinc material, it offers a wide pressure regulation range and reliable performance in various industrial applications.

Manufacturer: FESTO

Type: Pressure Regulator

Model: LR-1/2-D-I-MIDI

Part No.: 192322

Size	MIDI
Fluid	Compressed Air / Inert Gas
Pressure Regulation Range	0.5 ... 16 bar
Operating Pressure Max.	16 bar
P1 Max.	16 bar / 240 PSI / 1.6 MPa
P2 Max.	12 bar / 130 PSI / 1.2 MPa
Nominal Flow Rate	3500 l/min
Pneumatic Connection	G 1/2
Material	Die-Cast Zinc
Ambient Temperature	-10 ... 60 °C
