Festo 529351 Feed Separator

Manufacturer: FESTO
Type: Feed separator
Model: HPV-14-20-A
Part No.: 529351

Stroke: 20 mm
Piston diameter: 14 mm
Cycle time: 223 ms
Operating pressure: 3 bar … 8 bar
Operating medium: Compressed air
Max. interchangeability: 0.3 mm
Max. tappet play Sx: 0.05 mm
Mode of operation: Double-acting
Theoretical force at 6 bar, advancing: 90 N
Position sensing: For proximity sensor
Pneumatic connection: M5
