Festo 537954 Double Solenoid Valve
Neu
Auf Lager2 EinheitenVersandbereit
69,99$
Double Solenoid Valve
The Festo VMPA2-M1H-B-PI double solenoid valve offers 5/3-way functionality with an operating pressure range from -0.9 to 10 bar. Its piston gate valve design and die-cast aluminum housing provide reliable performance in compressed air systems.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Festo VMPA2-M1H-B-PI “ Double Solenoid Valve
The Festo VMPA2-M1H-B-PI double solenoid valve is designed for precise control in pneumatic systems. With its 5/3-way function and durable die-cast aluminum housing, it operates efficiently with compressed air across a wide range of pressures and temperatures.
Manufacturer: Festo
Type: Double Solenoid Valve
Model: VMPA2-M1H-B-PI
Part No: 537954
| Type of Actuation | Electrically |
| Function | 5/3 way |
| Operating Pressure | -0.9 bar to 10 bar |
| Operating Medium | Compressed air |
| Flow Rate | 450 l/min |
| Design | Piston Gate Valve |
| Ambient Temperature | -5 to 50 °C |
| Pneumatic Connection | Sub-based |
| Material Seals | NBR |
| Material Housing | Die-cast aluminum |
| Protection Degree | IP65 |
