Festo 552790 ISO Cylinder

Manufacturer: FESTO
Type: ISO cylinder
Model: CRDSNU-25-200-P-A
Part No.: 552790

Stroke: 200 mm
Piston diameter: 25 mm
Cushioning: Elastic cushioning rings/pads at both ends
Operating pressure: 1 bar … 10 bar
Mode of operation: Double-acting
Ambient temperature: -40 °C … 120 °C
Theoretical force at 6 bar, retracting: 247 N
Theoretical force at 6 bar, advancing: 295 N
Pneumatic connection: G1/8
Cover material: High-alloy stainless steel
Piston rod material: High-alloy stainless steel
