Festo 8714 END Stop Limit Switch
Gebraucht
Auf Lager1 EinheitVersandbereit
END STOP LIMIT SWITCH
SDK-3-PK-3 mechanical end stop switch with ball seat structure, 0.6 mm nominal width, and spring reset for pneumatic systems.0.6ActuatedBallControlEndIndustrialLimitMechanicalmmNominalPneumaticResetSDK-3-PK-3SeatspringStopSwitchWidth
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SDK-3-PK-3 END STOP LIMIT SWITCH
The SDK3PK3 is a mechanically actuated end stop limit switch designed for precise pneumatic control. Built with a ball seat structure and mechanical spring reset, it ensures reliable operation under varying pressure and temperature conditions.
Type: End Stop Limit Switch
Model: SDK-3-PK-3
Part No.: 8714
| Nominal Width | 0.6 mm |
| Actuation Type | Mechanical |
| Operating Pressure | 0 / 8 bar |
| Standard Nominal Flow Rate | 16 l/min |
| Actuating Force | 12 N |
| Structural Design | Ball Seat |
| Reset Method | Mechanical Spring |
| Pneumatic Connection | PK-3 |
| Ambient Temperature | -10 / 80 °C |
