FYH UCF 210J Four-Bolt Square Flange Unit
Neu
Auf Lager18 EinheitenVersandbereit
Vier-Schrauben-Vierkantflansch-Einheit FYH UCF 210J mit einem Bohrungsdurchmesser von 50 mm und einer Gesamtlänge von 143 mm. Entwickelt für hohe Tragfähigkeit mit Gewindeschraubensicherung, ideal für sichere Montage in industriellen Anwendungen.
210J35.150bearingborecomasDynamicFlangeFour-BoltFYHIndustrialkNLoadlockingmmscrewSetSquareUC210UCFUnit
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
FYH Four-Bolt Square Flange Unit UCF 210J
The FYH UCF 210J Four-Bolt Square Flange Unit offers reliable support and secure attachment in industrial applications. With a cylindrical bore and high load ratings, it ensures long-lasting performance in demanding environments.
Manufacturer: FYH
Model: UCF 210J
Type: Four-Bolt Square Flange Unit
Housing No.: F 210
Bearing No.: UC210
| Bore Diameter | 50 mm |
| Overall Length | 143 mm |
| Housing Overall Width | 40 mm |
| Width of Inner Ring | 51.6 mm |
| Distance Between Attachment Bolts | 111 mm |
| Overall Unit Width | 54.6 mm |
| Bolt Size | M14 |
| Dynamic Load Rating | 35.1 kN |
| Static Load Rating | 23.3 kN |
| Locking Device | Set screw locking |
| Bore Type | Cylindrical |
